1140644 ~ McNeilus ~ Dust Collector Filter

$142.70

$164.66

1140644 Specifications

Original Manufacturer

McNeilus

Model Number

1140644

Dimensions and Design

12.75 x 27.375 x 8.375, Outside diameter:12.75, Length: 27.375, Inside diameter: 8.375, Top: open, Bottom: closed, Shape: round, Media Square ft.: 234.41 ~ Bolt Hole OCB 0.540"

Filter Media Specs

DCF Cellulose / Polyester 80/20 Blend (Spunbond or Nanofiber variations availible on request.)

Max Temp Rating 180 F.
MERV 11
Caliper 0.29
Mullen Strength
  Dry 51.8 PSI
  West 36.6
